DMXking eDMX8 MAX - ArtNet/sACN to DMX Controller
Ready to be shipped from our US-based warehouse.
Description
Rugged 8 port DMX512 node. Fully protected and isolated DMX512 IN/OUT independently configurable ports with advanced stream merging and built in show recording for standalone operation. Built tough with plenty of mounting options the eDMX8 fits nicely in your lighting rig by simplifying cable runs and eliminating the need for DMX distribution amplifiers/splitters. Mount an eDMX8 closer to the rig and run Ethernet cable back to the controller and better still power the eDMX8 right back at the controller up to 70m / 210feet away using Power over Ethernet. Can also be powered via USB-C.
Supporting both DMX512 output and DMX512 input individually configurable on each channel along with Art-Net and sACN protocols the eDMX8 is an ideal choice for universe hungry lighting rigs. The flexible configuration permits 2 input DMX merge functionality too. Designed and manufactured in New Zealand to the highest standards.
Recording/playback requires approved/tested SD card models (see recording manual for details).
Features
Power Options:
- PoE injector (not included)
- 802.3af compliant network switch
- USB-C adapter (not included)
Configuration:
All configuration options are stored in non-volatile memory on the device, so even if you need Windows/MacOSX for the configuration utility, you can still use this with other computers/devices once it's configured.
Supporting both Art-Net and sACN the eDMX8 is ideal for when you need the top-of-the-line DMX512 node with support for 8 universes.
Main Features:
- Static IP or DHCP network addressing.
- Supported operating systems: Any with Ethernet networking support. Windows, MAC OS, Linux, iOS, Android.
- Tough metal enclosure with multiple mounting options
- Available with 3pin or 5pin Neutrik XLR socket options
- 8x DMX512 Out or DMX512 In with Art-Net, sACN E1.31 and E1.20 RDM support
- Merge 2 incoming Art-Net streams per output channel with both HTP and LTP options
- Merge Art-Net + DMX input -> DMX output(s)
- Merge 2x DMX input -> DMX output(s)
- sACN Priority takeover for multi-tier controller arrangements
- Mix and match ArtNet with sACN merge/priority sources
- 1500V Isolation between every port
- E1.11 Higher Protection Level “DMX512-A Protected” device.
- Power over Ethernet 802.3af compliant and etherCON for network connection. Alternative power via USB-C.
- Fully compatible with *ALL* software and hardware that supports Art-Net I, II, 3 & 4 and sACN protocols.
- Works with your existing console if Art-Net or sACN external nodes are supported.
- Universe Sync Art-Net, sACN and Madrix Post Sync.
- Recording and playback to microSD card (not included). See eDMX PRO Record / Playback manual.
- Standalone show playback without a computer or network connection.
- Configuration utility (Win/OSX) with basic Art-Net output/input test functionality (Win only).
- Firmware updates can be performed by the end user.
